With its printing width of 3.3m and latest RICOH GEN5L print head specially for the textile printing industry, the Teleios G5 is the latest and the most advanced direct to fabric printer till date. It provides high resolution of 600dpi with true grey scale and along with its high speed heat-fixation unit HeatMAN that automatically adjusts speed and temperature, it has absolutely no competition in the market.

  • Touch panel & workstation stand >> The touch panel for easy handling of precise work and workstation(option) for rip s/w operation are concentrated for simple operation.
  • Printing unit >> The latest print head with 1,152 nozzles per color and 19.5cm printing band which enables to print as speed up to 180 m2/h
  • Patented cylinder system >> d.gen’s unique cylinder system for roll to roll fabric feeding may allow direct printing on fabrics like knit, power stretch, etc., without sticky belt
  • Ink Container for 2kg of ink Pouch >> The Teleios Grande's ink container for 2kgs ink pouch for 6 colors allows refilling inks while printing without staining your hands
  • Air wiper >> The air wiper cleans dust without any contact nor damage to sensitive print heads for high quality production Continuously
  • Air gun >> The standard equipped airgun allows easy handling of air shaft for stable feeding of heavy and grand width fabric rolls.
  • Maximum Printing width : 3,300 mm
  • Printing Method : Piezo inkjet (Ricoh GEN5)
  • Maximum Resolution : 1200 dpi
  • Target Printing Speed - 1 pass 300 m2(3230 ft2)/h
  • Target Printing Speed - 2 pass 185 m2(1992 ft2)/h
  • Target Printing Speed - 4 pass 98 m2(1055 ft2)/h
  • Target Printing Speed - 6 pass 60 m2(646 ft2)/h

Direct Printing Fabrics
